    High Efficient Candy Making Equipment For Jelly Small Candy Easy Operating

    Ask Lasest Price
    Brand Name : Huanxuan
    Model Number : HX-150 to 300
    Certification : CE Certificate
    Price : Negotiable
    • Product Details
    • Company Profile

    High Efficient Candy Making Equipment For Jelly Small Candy Easy Operating

    High efficient factory price jelly small candy making machine


    1. Machine Brief Introduction of jelly small candy making machine :

    This soft candy processing line is an advanced continuous plant for making different sizes and colors of soft/gummy candies. It is a ideal equipment which can produce out good quality products with one color or two colors and saving of both the manpower and the space occupied. This depositing line consists of dissolving cooker, gear pump, storage strainer, storage tank, discharging pump, color and flavor mixer, depositor, cooling tunnel, electric control cabinet etc.

    2. Feature of jelly small candy making machine :

    1) PLC /computer process control available;

    2) An LED touch panel for easy operating;

    3) The main body is made of Stainless Steel

    4) Optional (mass) flowing controlled by Frequency inverters;

    5) In-line injection, dosing and pre-mixing techniques for the proportional addition of liquid;

    6) Dosing pumps for the automatic injection of colors, flavors and acids;

    7) Use automatic steam control system instead of manual steam valve which controls a stable steam supply to the microfilm cooker.

    3. Specifications of jelly small candy making machine :

    Model

    HX150

    HX300

    Production capacity

    150kg/h

    300kg/h

    Rated Depositing times

    60 (n/min)

    Weight ofcandy

    Two color

    1-6g/pc

    One color

    power

    Voltage

    380v

    power

    18kw

    27kw

    Compressed air needed

    Dosage

    0.2m3/min

    0.25 m3/min

    Pressure

    0.4-0.6mpa

    Conditions needed for cooling system

    20-25℃ 55% humidity

    Dimension

    9400*1100*1800mm

    10000*1600*1800

    Gross Weight

    4000kg

    4500kg


    Q: How can we get detailed quotation form you?
    To save your valuable time, please kindly provide information as follows with your inquiry:
    1. The Target Capacity (kg/h) you need;
    2. Type of candy picture you want to make;

    3. Type of heating device (electric or steam);
    4. Your plant length and width if have;


    Q:Do you a professional food machienry manufacturer?
    Yes, we do. Our team have more than 20 yesrs experience , we are professioanl for the food equipment and export business. And we are know what the customer needs, we can supply
    good quality products and competitive price to you.


    Q: What methods of Payment are Acceptable?
    1) Telegraphic transfer(T/T). If you order is standard machine, just need T/T 30% as deposit before production, then 70% T/T balance before shipment.
    2) Western Union
    3) L/C: 100% L/C Irrevocable at sight
